Your current location：Home - Products - Precision electric cylinder - Linear moduleLinear unite refers to the general term for devices capable of linear motion in the field of automation industry, also referred to as positioning modules. Linear modules can be considered as mechanical engineers through the transformation of machinery and machinery development, mutual sharing of experience and exchange of knowledge, and finally come to a common knowledge products.
classification
Linear modules in the development of different areas of automation industry, differentiation, large number of specifications, machine common linear modules in several forms:
Manual mechanical form
Electric drive form
Jiong a linear module
Column type low assembly linear guide form
Kk precision linear module
TCD linear slide
由于不同的規格影響著不同的結構發展，因此不能在線性模組的規格上統一結構。但是從結構上可以分外部結構和內部結構。
內部
線性模組內部結構分為：同步帶式和滾珠螺桿式。
同步帶式：線性模組的傳動方式由皮帶 和直線導軌輔助完成。
滾珠螺桿式：線性模組的傳動方式由滾珠螺桿，和直線導軌輔助完成。
線性模組封閉式圖示(9張)
線性模組的外部結構分為：開放式和封閉式。
開放式：線性模組的受力部分主要集中在中下部和兩側，將其傳動部分裸露在外。
封閉式：線性模組的受力部分主要集中在外部材料，將其傳動部分封閉起來。
線性模組與馬達的連接方式分為：間接式和直接式兩種，同時同創達為了方便用戶更好設計所需，可以根據
客戶需求選擇要不要配備馬達。
動力源一般選擇 步進電機 和伺服馬達，具體根據實際需求選定。
|
